The YQ81F Liquid Cooling Quick-Install Ball Valve is designed specifically for high-efficiency connection in data centers, energy storage systems, and high-performance computing cooling loops. Featuring an international standard tri-clamp connection, this valve allows for rapid assembly and disassembly within seconds without tools, significantly enhancing maintenance efficiency for liquid cooling modules. Precision-cast from stainless steel and lined with stable fluoroplastic seals, it ensures zero leakage and high purity when handling deionized water, glycols, or perfluoropolyethers.

Product Image:YQ81 Liquid Cooling Quick-Install Ball Valve

1、Rapid Connection Structure: Uses ISO standard tri-clamps for installation, making it ideal for space-constrained liquid cooling cabinets that require frequent maintenance.

2、Full-Bore Low Pressure Drop: The ball channel matches the pipe diameter with smooth internal walls, minimizing flow resistance and pump energy consumption.

3、Wide Media Compatibility: Optimized for specialized liquid cooling fluids like synthetic oils and HFEs, preventing chemical leaching and protecting sensitive electronics.

4、Compact & Lightweight: Reduces volume by over 40% and weight by approximately 50% compared to flanged valves, lowering the load on piping supports.

5、Blow-out Proof Safety: The stem features an internally loaded design with anti-static properties, ensuring operator safety even during pressure surges.

6、High Surface Cleanliness: Electropolished or precision-machined surfaces eliminate burrs and dead zones, preventing microbial growth in the cooling system.

Structure Diagram:YQ81 Liquid Cooling Quick-Install Ball Valve

Material List

Performance Specification Sheet

Standard requirements for external dimensions

Product approved by PED97/23/EC (CE0036)

Casting approved by AD2000-W0

Inspection & Testing: API598, EN12266

Outline Diagram:YQ81 Liquid Cooling Quick-Install Ball Valve

Outline Dimension Table   （Unit:mm）

Due to the rapid R&D iteration speed of valve products from China Kaivex Valve Group Co., Ltd., the above technical parameters and specification documents, including product overview, features, parts materials, outline dimension charts, CAD drawings, and product instruction manuals, are for your reference only. For actual applications, please contact our valve sales engineers to obtain the support you need for free. Thank you!
