Dual Safety Integration (Ex-proof & Anti-Corrosion): Outfitted with fully enclosed, high-tier explosion-proof coils, this valve is fully authorized for safe long-term deployment in hazardous areas (such as Zone 1 and Zone 2). The pure UPVC/CPVC body entirely eliminates the risk of metal corrosion failure, preventing catastrophic chemical leakages.
Dual Thread Standards for Global Adaptation: Conveniently available with both G threads (55° British Standard Pipe Parallel Thread) and NPT threads (60° American National Standard Taper Pipe Thread). This enables direct, seamless integration into international piping manifolds without the need for cumbersome thread adapters.
Large Bore with Minimal Pressure Drop: Utilizing a refined pilot-diaphragm configuration, the valve requires a remarkably low differential fluid pressure to actuate smoothly across the entire 0.3 to 6 bar operating envelope. The flow path is optimized for fluid dynamics, maximizing flow coefficient (Cv) and minimizing flow resistance.
Fatigue-Resistant Diaphragm for Extended Service Life: The internal diaphragm is fabricated from an elite, chemically cross-linked elastomeric polymer, providing unmatched fatigue resistance and chemical immunity. Even under prolonged, high-frequency continuous automated cycles, it retains exceptional resilience and a zero-leakage seal, driving down operational downtime.
Excellent Structural Rigidity & Temperature Tolerances: Features thick-walled housing geometry. The UPVC configuration is ideal for ambient corrosive lines, while the CPVC upgrade safely elevates the fluid temperature threshold up to 50°C while mitigating linear thermal expansion stresses.
