Dual Flange & Union Connection: The hybrid design combining a union nut and a flange provides both the high-pressure endurance of a flanged joint and the flexible, non-destructive disassembly of a union. This drastically reduces installation difficulties in multi-valve manifolds or confined spaces.
Zero Differential Pressure Capability: Equipped with an assisted-lift diaphragm structure, the valve operates reliably across a pressure range of 0 to 7 Bar without requiring a minimum pressure drop or fluid backpressure.
All-Plastic Corrosion-Resistant Body: Specifically tailored for chemical and high-purity fluids, the valve body (available in UPVC or PP) completely eliminates metallic oxidation and corrosion in aggressive acid, alkali, or salt-mist environments, preventing secondary fluid contamination.
Premium Seals & High Flow Capacity: Fitted with a long-life NBR diaphragm as standard (EPDM or Viton available upon request). The internal flow path features a large-orifice, low-resistance design to ensure excellent flow rates and high Cv factors.
Industrial Protection Coil: Rated at IP65 with a standard DIN junction box, the coil ensures a low temperature rise and robust encapsulation, effectively resisting dusty, humid, and mildly corrosive atmosphere inside industrial workshops.
