1. High-pressure energy dissipation and cavitation resistance: The valve body features a streamlined, axisymmetric flow channel design that significantly reduces noise and vibration. Its unique piston-and-cage (fan ring) structure effectively dissipates energy through multi-hole jet collisions, ensuring cavitation prevention even under inlet/outlet pressure differentials up to 40 kg/cm², thus safeguarding pipeline systems.
2. Reliable sealing with zero-leakage closure: Featuring a metal-to-metal primary seal and floating valve seat design, it delivers exceptional sealing performance. When fully closed, the valve ensures complete leakage-free operation, making it a reliable shut-off valve.
3. High resistance and durability with extended service life: The specially designed flow path and robust piston structure enable it to handle fluids containing small particles like sand. Critical components such as valve seats and guide rails are made of special stainless steel, with a hardness three times that of ordinary stainless steel, offering excellent wear and corrosion resistance. The designed service life reaches up to 30 years.
4. The intelligent valve features excellent linear regulation characteristics across the full flow range, ensuring stable and precise control. It can be equipped with electric drive devices, PLC control systems, and sensors to achieve both local and remote intelligent automation, with user-friendly operation.
5. The operating force is small and the flow resistance is low. The motion direction of the operating part (piston) is consistent with the direction of the fluid, and the operating torque is small. The optimized flow channel makes the pressure loss of the valve small, which helps to reduce the power consumption of the pipe network.
